HMI (Graphic Terminals)

HMI (Graphic Terminals)


Graphic Terminals offer rugged electronic interface solutions in a variety of sizes, operator input methods, memory options and configurations. These robust devices are fully packaged (hardware, software and communications) and tested for human-machine interface operation. They have earned ratings for high shock, vibration, and temperature. Access your application information over a variety of communication protocols including Device Net™, ControlNet™, and Ethernet/IP™.

Features

  • Provides significant improvements over the Panel View™ Plus 400 graphic terminals
  • Processor speed increased from 350 MHz to 1 GHz
  • Screen transition rate is up to 70% faster
  • System memory increased from 64MB RAM to 256MB RAM
  • Flash storage space increased from 64MB to 512MB
  • Includes 80MB nonvolatile storage for applications
  • Increased illumination of LED backlight displays
  • Greater connectivity to a variety of peripherals such as printers, mice, and keyboards
  • Supports ActiveX® Controls
  • Integrates with third-party software such as Microsoft® Internet Explorer® and Microsoft Office Viewers
  • Supports remote connectivity (VNC and FTP)
  • Offers backup restore functionality
  • Provides remote recipe and data management through .CSV files
  • Uses vector-based graphics from Symbol Factory
  • Includes built-in PDF viewer for context-sensitive operator support
  • Supports Data Store Plus logging and trending, which eliminates the 300,000 data point limit
